Integrating essential power management functions for small devices into one chip, contributing to space-saving design Epson's Power Management IC (PMIC) for small devices, such as hearing aids and smart rings, integrates essential power management functions (battery charging, protection, and power supply) into one chip, greatly contributing to device space-saving. Additionally, Epson's proprietary wireless power supply technology enables stable wireless power transfer. The products include models that support both wireless charging and contact charging, as well as models specialized for contact charging, offering a lineup that can be selected based on various applications and needs.


Features of Epson PMIC

  1. Stable wireless charging

    • Epson's unique wireless charging technology provides stable, contactless power transmission to devices.
  2. High-efficiency Step-Down Charge Pump Circuit for main system IC

    • Equipped with a highly efficient step-down charge pump circuit for main system IC, boasting a conversion efficiency of over 90%(>2mA). This eliminates the need for additional power ICs for main system IC.
  3. Comprehensive protection features

    • Includes protection circuits for overcharge/discharge, overcurrent, and overvoltage, ensuring reliable battery protection.
  4. Flexible charging parameter settings

    • The built-in Flash ROM allows customizable charging parameters tailored to the battery, contributing to extended battery life.

Product Lineup

  • Models Supporting Both Wireless and Contact Charging

    S1A00112B
    (For Receiver-Side Devices) S1A00121F
    (For Transmitter-Side Devices)
    These models support both contact and wireless charging. Proprietary wireless power supply technology enables stable power transmission even with small coils. By combining the transmitter-side dedicated IC "S1A00121F" with the receiver-side dedicated IC "S1A00112B," efficient charging solutions and bidirectional data communication are made possible.
    S1A00112B Brief Sheet PDF
    S1A00121F Brief Sheet PDF
    S1A00210B
    (For Receiver-Side Devices)
    MP Orders Start:Nov.25
    This PMIC features enhanced charging capabilities, constant voltage output, a step-down charge pump circuit compatible with heavy loads, low-power consumption LDO, and an SBD rectifier circuit.
    (For more details, refer to the bottom of the webpage.)

    S1A00210B Brief SheetPDF
  • PMIC Specialized for Contact Charging

    S1A00114B
    (For Receiver- side Devices)
    A model based on the S1A00112B, specialized for contact charging and designed to achieve lower costs.
    S1A00114B Brief Sheet PDF
    S1A00115B
    (For Receiver-Side Devices)
    A model based on the S1A00114B, providing the necessary functions for contact charging while achieving even lower costs and a more space-saving design.
    S1A00115B Brief Sheet PDF

Function Comparison Chart

  • For Receiver-Side

    Function S1A00112B
    MP
    S1A00114B
    MP
    S1A00115B
    MP
    S1A00210B
    Under Development
    Wireless Power Supply Rectifier Circuit
    - -
    Regulator - -
    Load Modulation Circuit - -
    Charging for Battery CC-CV Charging
    Temperature-Range- Compatible Control
    Power supply Charge Pomp Circuit for Main System x1/3 V Down x1/3 V Down x1/3 V Down 1.2V,x1/3 V,1/2V Auto-Switch
    1.8V-3.0V LDO - - -
    Protection Functions Over-charge/Over -discharge Protection
    Others Main System Communication -
    External Sensor Device Trigger Control -
    Battery Status Detection -
  • For Transmitter-Side

    Function S1A00121F
    MP
    Wireless Power Transmission 0.1W Power Transmission
    Automatic Switching of Coil Drive Mode
    (Half/Full Bridge)
    Communication Function Load Modulation
    Protection : Safety Circuit Temp Monitoring/ VCC Monitoring/ PMOS short Detection
    Others Removal / Landing Detection

Next-Generation PMIC S1A00210B

The S1A00210B, currently under development, expands the charging voltage range from the conventional 4.75V–5.25V to 2.3V–5.25V, enabling compatibility with a wider variety of devices. Additionally, the charging current has been significantly increased from the conventional 30mA (max) to 300mA (max), making fast charging possible. Furthermore, the internal flash memory allows up to two charging profiles to be stored. These profiles enable fine-tuning of parameters for CC-CV charging and settings for battery degradation prevention, contributing to enhanced reliability and product quality.The reservation for engineering sample is scheduled to begin in late April, with shipments planned for August and order acceptance starting in November of the same year. For more details, please refer to the brief sheet.

Item Conventional Product
S1A00112B
Under Development
S1A00210B
Wireless Power Transmission Built-in Built-in
Charging Voltage Range 4.75V~5.25V 2.3V~5.25V

Charging Current

  • Contact Charging: 40mA max
  • Wireless Charging : 20mA max
  • Contact Charging: 300mA max
  • Wireless Charging : 20mA max

System Power Supply

  • x1/3V Step-Down Charge Pomp Circuit
Step-Down Charge Pump: Auto-switching step-down based on load
  • 1.2V constant voltage output
  • LDO: Configurable 1.8V-3.0V
I2C Interface 4pin I2C channel
  • Charge/discharge profile settings
  • Charge/discharge status read
  • Send control commands
2pin I2C Channel
  • Charge/discharge profile settings
  • Charge/discharge status read
  • Send control commands
Flash Memory Used for IC function settings Used for IC function settings and charge/discharge profiles
Package WCSP-42pin
Approx 2.4×3.6×0.6mm
WCSP-48pin
Approx 2.5×3.4×0.5mm

Brief Sheet

S1V3G340 Data Sheet
219KB
S1A00210 Brief Sheet
326KB
